With a long-range 1D/2D scanning engine, the XG663 reads barcodes from as close as 2.2 inches to as far as 46 feet, reducing the need for repositioning or climbing to reach codes in hard-to-access areas. Whether scanning labels on high warehouse racks or close-range assets, the XG663 delivers fast, omnidirectional scanning with a safe and visible LED aimer.
Built with industrial-grade ruggedness, the XtremeScan housing features IP67 sealing to protect against dust, water, and rough handling. The pistol grip handle offers added comfort and control for extended scanning sessions, making it ideal for demanding, high-volume environments. The magnetic attachment system, combined with Bluetooth connectivity, offers a secure, convenient, and flexible way for employees to pair their mobile devices with high-performance scanning—seamlessly fitting into any mobile workflow.
Available in the following bundles
Magnetic Adapter Compatibility
To ensure proper magnetic attachment, please ensure your device is equipped with a compatible magnetic mounting system.
- Rokform Case Users: If you're using a Rugged Rokform Case for iPhone 15, 16, or 16e, no additional adapter is needed.
- Other Phones: For other devices, we recommend one of the following magnetic adapters from Rokform:
- Tablets: For tablet setups, we suggest the Oqtiq Magnetic Universal Strip as a reliable third-party option.
-
Rapid Scanning
Fast 1D/2D scanning for both printed and on-screen barcodes, featuring omnidirectional capability for intuitive, rapid scanning.
-
Advanced Decoding
Accurately captures data from scratched, damaged, smudged, or low-contrast barcodes, helping to reduce failed scans, minimize delays, and increase productivity when working in challenging environments.
-
Rugged Design
Built to withstand drops and harsh environments, with an IP67 sealed housing for protection from dust, water exposure, and water immersion.
-
One-Handed Solution
Easily combine the mobile device and data reader for a one-handed scanning solution.
-
Bluetooth LE Support
Enables dependable, low-power wireless connectivity for extended battery life and fast pairing through Bluetooth Low Energy.
-
Long-Lasting Battery
Scanner features rechargeable and field-replaceable battery that lasts a full shift.
-
Intuitive User Indicators
LED lights that indicate successful data read/write and battery charging status.
-
Audible Feedback
Multiple feedback tones to indicate successful data read/write and other important action confirmations.
-
Easy App Integration
Socket Mobile's Capture SDK enables easy integration in your applications to improve business productivity with fast, efficient, and reliable data transfer over Bluetooth wireless technology. Data reader works out of the box for apps that have already integrated CaptureSDK, with support for Bluetooth LE devices.
-
Developer Support
Our support team is available to assist with set-up and operation.
-
Interchangeable Scanner
Data reader can be detached & used separately, attached to a different iPhone/iPod, or inserted into any DuraSled Case.
-
Extended Range
Scans barcodes ranging in size from 5 mil to 160 mil, at distances from 2.1 inches to 14 feet.
-
LED Aimer
Bright, rectangular illumination field with LED pointer for precise aiming.
-
Magnetic Contacts
Easily connects to charging dock using magnetic connectors.
-
Pistol Grip Handle
Comfortable point-and-shoot barcode reading.
-
Multi-Device Compatibility
Compatible with Apple® iOS devices (iPhone®, iPad®) as well as Android® and Windows® 10 & 11.
-
1-Year Warranty Included
Extended warranty options also available.
| Default Barcode Symbologies |
Learn how to enable and disable data types. |
| Supported Barcode Symbologies |
Learn how to enable and disable data types. |
| Battery Type | 1 rechargeable Lithium Ion Polymer (replaceable battery) |
| Charge Time | 8 Hours |
| Life of battery | 500 charge-discharge cycles |
| Life per full charge | Standby time: 25 hours Active Scan Time: 10,000 scans within 11 hours (based on one scan every 4 seconds) Note: Battery life varies depending on ambient temperature, ambient light, and the age of the battery. |
| Battery weight | 12.5g |
| Percentage lithium | 36.3% |
| mAh | 700 |
| Cells per battery | 1 |
| Watts per battery | 2.59 |
| Cell type | Proprietary |
| Chemical composition | Lithium - polymer |
| Lithium content | 4.5g |
| Voltage | 3.7v |
| Hazmat UN Number | UN3481, P.I. 967 |
| ROHS Compliance | Yes, Included with Scanner |
| Country of origin | China |
| Commodity code | 8507.60.0000 |
|
Bluetooth LE |
|
|
Up to 10 meters (33 ft.), depending on the environment. The range limit is usually due to the Host Device (phone, tablet, or notebook). |
|
|
- Data Reader
- Charging Cable with USB-C to USB-A adapter
- Get Started Guide
|
From 0 to 100 000 lux. From pitch black to direct sunlight. |
|
|
Charging in an ambient temperature above 40° C / 100° F may result in charging issues. |
|
|
Standard:
Freezer:
|
|
|
0° to 45° C (32° to 113° F) |
|
|
95% at 60° C (140° F) (non-condensing) |
|
|
IP67 (Ingress protection rating for dust and water) meets IEC sealing and EN60529 specifications. |
|
|
-40° to 70° C (-40° to 158° F) |
